Ruijie Reyee RG-EST450G Wireless Bridge Base Station 120° FOV
Ruijie Reyee RG-EST450G Wireless Bridge Base Station 120° FOV - Image 2
Ruijie Reyee RG-EST450G Wireless Bridge Base Station 120° FOV - Image 3

Ruijie Reyee RG-EST450G Wireless Bridge Base Station 120° FOV

$256.00

PDF: EST450G Spec Sheet
PDF: EST450G Quick Start Guide
PDF: EST450G Installation Guide

SKU: 202436 Category:

Description

Ruijie Reyee RG-EST450G Wireless Bridge Base Station 120° FOV

Highlight Features

  • H: 120°, V: 13°
  • 3 x GE Ports
  • Support 3 Power Supply Options: 12 V DC, Passive PoE, 802.3af/at
  • One-Touch Pairing for PTMP Mode
  • Support TDMA
  • Support SON
  • IP55 Weatherproof

Ruijie Reyee Wireless Bridge Setup Video

Ruijie Reyee Point to Multi Point Setup Video

Ruijie Reyee Point to Multi Point Project Setup Video

Specifications

Wi-Fi Radio
Radio design: Dual-radio, 3 spatial streams. Radio 1: 2.4 GHz, 1 spatial stream: 1 x 1, SISO.  Radio 2: 5 GHz, 2 spatial streams: 2 x 2, MIMO
2.4 GHz channel width Auto/20/40 MHz

5 GHz channel width Auto/20/40/80 MHz

Power Supply and Consumption
Number of PoE In ports: 1
Number of PoE/PoE+ In ports: 1

Software Specifications
WLAN
   Bridge speed test: Yes
Ethernet Switching
   Link aggregation: No
Network Management and Monitoring
SON: Yes
AI heatmap: Yes
Restarting devices through Ruijie Reyee App: Yes
SNMPv1, v2c, and v3: Yes

Operating Band: IEEE 802.11b/g/n: 2.400 GHz to 2.483 GHz IEEE 802.11a/n/ac: 5.150 GHz to 5.350 GHzIEEE 802.11a/n/ac: 5.470 GHz to 5.725 GHzIEEE 802.11a/n/ac: 5.725 GHz to 5.850 GHzNote: Available bands vary with countries and regions. To use the preceding frequency bands, ensure that your country or region supports these frequency bands. For details, see Channels for Countries & Regions (official website link to be added)

Wi–Fi standardWi–Fi 5 (IEEE 802.11ac) standard, compatible with IEEE 802.11a/b/g/n standards2.4 GHz Wi–FiWi–Fi 4 (IEEE 802.11b/g/n)5 GHz Wi–FiWi–Fi 5 (IEEE 802.11ac)2.4 GHz channel widthAuto/20/40 MHz5 GHz channel widthAuto/20/40/80 MHzTransmission rateMaximum wireless data rate: 1166 Mbps●Radio 1: 2.4 GHz, 300 Mbps●Radio 2: 5 GHz, 866 MbpsMaximum transmit power2.4 GHz: 20 dBm (20 dBm per link)5 GHz: 29 dBm (26 dBm per link)

Receive  Sensitivity: 802.11b: -91 dBm (1 Mbps), -88 dBm (5 Mbps), -85 dBm (11 Mbps）802.11a/g: -89 dBm (6 Mbps), -80 dBm (24 Mbps), -76 dBm (36 Mbps), -71 dBm (54 Mbps)802.11n: -83 dBm@MCS0, -65 dBm@MCS7, -83 dBm@MCS8, -65 dBm@MCS15802.11ac HT20: -83 dBm (MCSO), -57 dBm (MCS9)802.11ac HT40: -79 dBm (MCSO), -54 dBm (MCS9)802.11ac HT80: -76 dBm (MCSO), -51 dBm (MCS9

Antenna2.4 GHz: 1 x 1 Built–in omnidirectional antenna 5 GHz: 2 x 2 Built–in directional antenna, horizontal: 120°, vertical: 13°
Antenna gain (2.4 GHz)2 dBi
Antenna gain (5 GHz)15 dBi
Antenna horizontal orientation120°
Antenna vertical orientation13°CPU: MT7628DA, single-core processor, 575/580 MHz clock frequency
Flash memory16 MB
RAM128 MB DDR3

Weight 0.83 kg (1.83 lbs) (without packaging materials)
Shipping weight1.61 kg (3.55 lbs)
Product dimensions (W x D x H)355 mm x 124 mm x 48 mm (13.98 in. x 4.88 in. x 1.89 in.) (excluding mounting bracket)
Package dimensions (W x D x H)415 mm x 185 mm x 113 mm(16.34 in. x 7.28 in. x 4.45 in.)
ColorElegant white

Number of fixed LAN ports3
Number of 10/100/1000BASE-T ports3
Reset button1
LEDs 1 x system status LED3 x Ethernet port LEDs3 x Signal status LEDs

Additional information

Weight 2 kg
